Expert calibration lab in
Roma – Italy
Opening hours
00154 Roma (RM)

ACCREDITATIONS
Ottieni servizi di taratura presso il nostro laboratorio accreditato di Roma, con riferibilità agli standard internazionali.

CAB 00297 calibration

ISO 17025
CAPABILITIES
Radiometry / Photometry
Global Calibration Scope
- Illuminance: 0.5 to 20 000 lux
- Luminance: 0.2 to 15 000 ㏅/m2…
Common equipment serviced: Illuminance meter, Luminance meter, Spectrophotometer, Glossmeter, Photometer, Colorimeter, Pyranometer, Irradiance meter
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Mass / Scale
Global Calibration Scope
- Mass: 1 mg to 1000 kg (range depending to class less than E2, F2, M1…)
- Scale: 1mg to 200 000 kg with weights class from E2, F1 to M1-2
- Legal metrology: maintenance and repair for scales up to 180 000 kg
Common equipment serviced: Weight, Weighing devices (Weighing scale, Hopper scale, Tank scale, Platform scale, etc), Weighing instruments for blood collection bags
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Liquid flow
Global Calibration Scope: Liquid flow (water): 0.12 l/h to 120 m3/h; Liquid flow (Hydrocarbon oils (Kerosene, Gas oil, Shell Tellus 32, Shell Tellus 100)): 0.6 l/min to 3000 l/min
Common equipment serviced: Liquid flow meter, Backflow gages, Flow analyzers, Gas flow meters, Flow transducers, Flow transmitters, Leak testers, Orifices, Rotameters, Turbine meters
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Gas flow
Global Calibration Scope: Gas flow (air): 0.5 ml/min to 4000 m3/h (the range is lower depending on gas used (nitrogen, argon or any inert gases)
Common equipment serviced: Anemometers (thermal & vane), Bubble flowmeters, Gas flow meters, Gas meters, Thermal mass flow controllers, Variable area flow meters, Backflow gages, Flow analyzers, Gas flow meters, Flow transducers, Flow transmitters, Leak testers, Orifices, Rotameters, Turbine meters
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Torque
Global Calibration Scope
- Torque measuring devices (sensors, transducers, measuring chains…): 0,001 to 5 000 Nm
- Hand torque tools (wrenches, screwdrivers …): 0,02 to 5 000 Nm
- Torque multiplier: 50 to 5 000 Nm
Common equipment serviced: Torque analyzer, Torque sensor, Torque tester, Torquemeter, Torque transducer, Torque multiplier, Torque gun, Torque wrench, Torque screwdriver, Joint simulator, Hydraulic torque wrench
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Force
Global Calibration Scope
- Push pull force measuring devices in tension and compression: up to 1 MN
- Force machine: up to 5 MN (compression) and up to 1 MN (tension)
Common equipment serviced: Dynamometers, Force machines (Tension and/or Compression), Load cell, Force gauges, Strainmeter, Crimping pliers, Charpy testers, Cable tie tools, Press, Retention tools, Wire wrap tools, Spring balance
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Dimensional
Global Calibration Scope
- Gauge block (steel, tungsten carbide, ceramic…): up to 1500 mm
- Long length (standard tape rules, peripheral gauges…): up to 100 m
Common equipment serviced: Angle instruments, Measuring bench/optical, Depth gauge, Gauge blocks, Height gauges, Micrometers, Length instruments, Limit gauges, Form and surface, Thread gauges
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Chemical
Global Calibration Scope
- Viscosity: kinematic and dynamic, consistometric cup, etc.
- Conductivity: Electrical (0 μS/cm to 200 mS/cm) and with Certified Reference Material (1,1 μS/cm to 111,3 mS/cm)
- Gas detector and Gas Concentration : Carbon monoxide, Nitrogen monoxide, Nitrogen dioxide, Oxygen, Total gaseous organic carbon, Dilution apparatus for olfactometry, Sulfur dioxide, Carbon dioxide, Hydrogen sulfide, Benzene, Methane, Ozone, Propane, etc.
- Refractometry: (1.33 ~ 1.62) nD (refractive index), 0 to 87.6% Brix, etc.
Common equipment serviced: Conductivity meters, Salinity meters, pH meters, Sucrose solutions, Gas detectors and gas concentration, Particle counters, Refractometry instruments, Viscosity instruments
This site holds the competency for the specified domain. If your requirement is outside the scope of competency, we may be able to transfer the instrument with your permission to another Trescal laboratory that holds the applicable scope. Please refer to the scope of accreditation for accredited capabilities specific to this laboratory.
Electricity
Taratura elettrica ACCREDIA e riferibile:
- Multimetri: fino a 1 kV, 20 A, 100 MΩ
- Pinze: fino a 1 kV, 1 kA, 100 MΩ
- Resistori: fino a 100 MΩ
- Shunts: fino a 1 kA
- Wattmetri/Contatori: fino a 480 V / 120 A / cosϕ trifase, 3 kA monofase
- Analizzatori di rete: fino a 480 V / 120 A / cosϕ trifase, 3 kA monofase
- Analizzatori o Calibratori sicurezza elettrica: Riso, GBR, RCD, RE, Rloop, Rlow, Ileakage, rigidità
- Sistemi alta tensione: fino a 60 kV DC e 40 kV AC
- Sistemi alta corrente: corrente diretta fino a 1 kA
- Calibratori per saldatrici: fino a 1 kV e 1 kA
Strumenti comuni per la taratura elettrica sono multimetri, pinze, resistori, shunt, wattmetri/contatori, analizzatori di rete, analizzatori di sicurezza elettrica, calibratori di sicurezza elettrica, sistemi ad alta tensione, sistemi ad alta corrente, calibratori per saldatrici.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Pressure / Vacuum
Taratura della pressione ACCREDIA e riferibile:
- Pressione: da -100 kPa a 500 MPa
Strumenti comuni per la taratura della pressione sono trasduttori, manometri, calibratori, barometri, vacuometri, bilancia di pressione digitale, compressometro e gonfiagomme.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Temperature
Taratura della temperatura ACCREDIA e riferibile:
- Temperatura: tra -196 °C e 1500 °C.
- Pirometri fotoelettrici con indicazione diretta: da 600 °C a 1400 °C con banda spettrale tra 0,7 μm e 1,1 μm
Strumenti comuni per la taratura della temperatura sono termocoppie, termoresistenze, termometri, calibratori, pirometri, misuratori di temperatura dell’aria.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Time / Frequency
Taratura di tempo e frequenza ACCREDIA e riferibile:
- Generatori e sintetizzatori: fino a 40 GHz
- Misuratori e frequenzimetri: fino a 40 GHz
- Oscillatori e oscilloscopi: 1 MHz, 5 MHz, 10 MHz; da 0,33 ns a 1 s
- Cronometri: da 0.1 s a 100000 s
- Conta-ore e contagiri: da 10 giri/min a 105 giri /min
Strumenti comuni per la taratura di tempo e frequenza sono generatori di segnali, frequenzimetri, cronometri, tachimetri, oscilloscopi, conta-ore e contagiri.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Taratura elettrica ACCREDIA e riferibile:
- Multimetri: fino a 1 kV, 20 A, 100 MΩ
- Pinze: fino a 1 kV, 1 kA, 100 MΩ
- Resistori: fino a 100 MΩ
- Shunts: fino a 1 kA
- Wattmetri/Contatori: fino a 480 V / 120 A / cosϕ trifase, 3 kA monofase
- Analizzatori di rete: fino a 480 V / 120 A / cosϕ trifase, 3 kA monofase
- Analizzatori o Calibratori sicurezza elettrica: Riso, GBR, RCD, RE, Rloop, Rlow, Ileakage, rigidità
- Sistemi alta tensione: fino a 60 kV DC e 40 kV AC
- Sistemi alta corrente: corrente diretta fino a 1 kA
- Calibratori per saldatrici: fino a 1 kV e 1 kA
Strumenti comuni per la taratura elettrica sono multimetri, pinze, resistori, shunt, wattmetri/contatori, analizzatori di rete, analizzatori di sicurezza elettrica, calibratori di sicurezza elettrica, sistemi ad alta tensione, sistemi ad alta corrente, calibratori per saldatrici.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Taratura della pressione ACCREDIA e riferibile:
- Pressione: da -100 kPa a 500 MPa
Strumenti comuni per la taratura della pressione sono trasduttori, manometri, calibratori, barometri, vacuometri, bilancia di pressione digitale, compressometro e gonfiagomme.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Taratura della temperatura ACCREDIA e riferibile:
- Temperatura: tra -196 °C e 1500 °C.
- Pirometri fotoelettrici con indicazione diretta: da 600 °C a 1400 °C con banda spettrale tra 0,7 μm e 1,1 μm
Strumenti comuni per la taratura della temperatura sono termocoppie, termoresistenze, termometri, calibratori, pirometri, misuratori di temperatura dell’aria.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
Taratura di tempo e frequenza ACCREDIA e riferibile:
- Generatori e sintetizzatori: fino a 40 GHz
- Misuratori e frequenzimetri: fino a 40 GHz
- Oscillatori e oscilloscopi: 1 MHz, 5 MHz, 10 MHz; da 0,33 ns a 1 s
- Cronometri: da 0.1 s a 100000 s
- Conta-ore e contagiri: da 10 giri/min a 105 giri /min
Strumenti comuni per la taratura di tempo e frequenza sono generatori di segnali, frequenzimetri, cronometri, tachimetri, oscilloscopi, conta-ore e contagiri.
Le tarature possono essere svolte presso i nostri laboratori o nella sede del cliente.
